CCD Filter
Recreate the glowing, cool-toned look of early CCD-sensor cameras — right in your browser.
No photo? Try a sample
Presets in this editor
Cool CCD
Loads automatically on this pageCleaner, slightly cool vintage sensor feel (subtle green/cyan lean).
The exact values this preset sets, so you can rebuild or tweak it by hand:
iPhone 4
Soft edges, gentle grain, slightly warm 2010s smartphone vibe.
Grain 38 · Softness 32 · Vignette 18
Warm Digicam
Golden-hour point-and-shoot warmth with punchy colors.
Grain 28 · Softness 18 · Warmth 66
Flash Pop
Harsh highlights + glow like a built-in flash at night.
Bloom 20 · Grain 18 · Contrast 60
Soft Nostalgia
Dreamy, faded, warm — heavy softness + bloom for a nostalgic vibe.
Softness 48 · Grain 30 · Bloom 26
2000s Y2K
Warm, faded early-digicam color with soft grain and a gentle vignette.
Grain 30 · Fade 18 · Softness 16
Disposable Flash
Hard close-flash glow, warm grain, casual single-use snapshot energy.
Grain 26 · Bloom 24 · Softness 12
Huji-Style
Warm flashed glow with grain, made for the corner date stamp.
Grain 29 · Softness 14 · Bloom 14
Dazz-Style
Cool CCD glow with extra bloom and old-sensor color fringe.
Grain 22 · Bloom 14 · Aberration 13
Kodak Gold
Golden film warmth with soft skin tones and fine grain.
Grain 22 · Warmth 63 · Softness 12
35mm Film
Fine grain and restrained, true-to-life analog color.
Grain 25 · Softness 14 · Vignette 8
Film Grain
Fine, even film texture over otherwise natural color.
Grain 35 · Softness 10 · Fade 10
Lomo Punch
Dark toy-camera vignette with loud, punchy color.
Vignette 30 · Grain 23 · Saturation 62
Vintage Fade
Old-print warmth with lifted blacks and darkened corners.
Grain 28 · Fade 21 · Softness 20
Polaroid
Washed instant-film fade with gentle warmth and a soft glow.
Softness 22 · Fade 21 · Vignette 20
Frequently Asked Questions
Photography shot on a CCD (charge-coupled device) image sensor, the chip used in most compact digital cameras from the late 1990s until roughly 2010. Charge is shifted across the chip to an output amplifier at the edge, and saturated pixels can overflow into their neighbours, which is why highlights bloom instead of clipping flat.
It recreates the look of cameras built around CCD image sensors, most compact digicams before roughly 2010. The signature traits are glowing highlights, slightly cooler and punchier color, and a fine, even noise instead of the smeared smoothing modern phones apply.
Where the charge becomes a number. A CCD moves it across the chip to an output amplifier at the edge; a CMOS sensor converts it in place at every pixel, which is faster and far more power-efficient, and is why phones use one. The CCD route is associated with the blooming highlights and fine even grain people now go looking for.
That bloom is the defining CCD trait. Bright areas bleed outward a little. If it is too strong, lower the Bloom slider; to push the effect, raise it.
Start with the Cool CCD preset, keep saturation moderate, add a little bloom and a touch of chromatic aberration, and keep grain fine rather than heavy. The glow in the highlights is what sells it.
Yes, and it is usually the better option. Old compacts have become expensive, the batteries are often dead, and they need memory cards you probably do not own. The cool cast, the highlight bloom and the fine grain are all reproducible on a photo you already have.
Yes. A clean phone photo going in and a CCD vibe coming out is exactly the point.
Ease off grain, lift the shadows slightly, and keep bloom gentle so skin stays smooth while the highlights still glow.
No. Everything is processed locally in your browser; your files are never uploaded.
About This Tool
The CCD look is having a real moment. Before phones took over, most compact "digicams" used CCD image sensors, and they rendered the world a little differently than the camera in your pocket does today: highlights bloomed instead of clipping flat, colors leaned cool and punchy, and shadows carried a fine, even grain rather than waxy smoothing.
This page recreates that signature CCD vibe. Load a photo and the Cool CCD preset is applied automatically. Then you can fine-tune. The two sliders that matter most are Bloom (how much the bright areas glow) and Aberration (a faint color fringe that reads as old-sensor optics).
For a convincing result, keep saturation moderate, let the highlights glow a touch, and keep the grain fine rather than heavy. On portraits, lift the shadows slightly and ease off grain so skin stays clean while the highlights still bloom. On street and daylight shots you can lean into the cool color a little more.
Everything runs locally in your browser, so your photo is never uploaded, and it works on phone photos, including HEIC files straight off an iPhone. It is free, with no sign-up and no watermark on your exports.
What a CCD sensor actually did
CCD stands for charge-coupled device. Both sensor types start the same way: a grid of tiny light buckets called photosites, each collecting light during the exposure and holding it as an electrical charge. The difference is what happens to that charge next, and it is one of several reasons photos from the two eras read differently. Sensor design is not the whole story: the lens, the flash and the camera's own JPEG processing all left fingerprints too.
A CCD shifts the charge from every photosite across the chip, bucket by bucket, to an output amplifier at the edge, so most or all of the frame is converted through the same path. (Faster CCDs used more than one output, so “a single amplifier” is the common case rather than a rule.) A CMOS sensor converts charge to voltage at or near each pixel instead, often with several photodiodes sharing the circuitry, and digitises further down the column. Phones went CMOS for speed, power, integration and cost together, not for image quality.
Worth being straight about the limits of this, though: the readout architecture is not what makes an old photo look old. Most of the character you are actually chasing came from the lens, the colour filter array, the white balance and the camera's own JPEG processing. The sensor is one ingredient among several.
| CCD | CMOS | |
|---|---|---|
| Where charge becomes a number | Shifted across the chip to one amplifier in the corner | Converted in place, at every pixel |
| Consistency across the frame | Typically very even, few conversion paths | Depends on per-pixel circuitry |
| Power draw and speed | Higher draw, slower readout | Lower draw, fast readout |
| Highlight behaviour | A saturated pixel can overflow into its neighbours, so bright areas bloom | Usually clips closer to flat white |
| Typical era in compacts | Late 1990s to roughly 2010 | Roughly 2010 onward, and every phone |
Neither is simply better. CMOS won the consumer market on speed, power and cost, while CCDs held on for years in scientific and industrial imaging where output uniformity mattered more than frame rate. What makes the older one interesting to photographers now is not that it was worse, but that its quirks are visible, and visible quirks read as human.
About that glow
There is a real sensor effect here and it is worth separating from the aesthetic one. Every photosite holds a finite amount of charge, and once a very bright area fills one to capacity the excess can spill into its neighbours. That is blooming. In practice it usually shows up as a hard streak running along the direction of the readout, not a pretty halo, and anti-blooming structures to drain the overflow existed long before these cameras reached shops.
The soft glow people actually associate with photos from this era owes at least as much to cheap lens elements scattering light, to flare, and to how the camera crushed the file into a JPEG. Which is fine for our purposes: you are recreating a memory of a look, not simulating a sensor. That is what the Bloom slider is for, and it is the one to reach for first.
Why people started buying these cameras again
The same reason film came back. Phone photos became so clean and so heavily corrected that they started to feel airless, and a flood of generated images made polish itself feel less trustworthy. A slightly cool, glowing, grainy photo looks like it came from a real moment and a real, imperfect piece of hardware.
The practical problem is that fifteen-year-old compacts now cost real money, the batteries are usually dead, and they want memory cards you no longer own. Reproducing the traits is cheaper, and it works on photos you already have.
Adjusting by subject
Ease the grain down and lift the shadows slightly so skin stays clean. Let the bloom carry the effect on bright cheeks and backlight rather than pushing texture.
Lean into the cool cast and keep contrast up. This is where the colour reads most convincingly, because it is the situation those cameras were used in most.
Push bloom harder than feels sensible. Bright point sources against a dark background are where old compacts most visibly struggled, and leaning into that is the whole appeal.
The mistake to avoid
Do not over-saturate. It is tempting to push colour until the photo pops, but real shots from these cameras are punchy, not neon. If skin starts to look orange or sunburnt, pull saturation and warmth back down.
See the difference
How to get the CCD look in three steps
- 1
Upload your photo
Drop in any photo. A modern phone shot works perfectly. Nothing is uploaded; it loads straight into the editor on your device.
- 2
Start from Cool CCD
The Cool CCD preset is applied automatically. It sets the cooler color cast and a little highlight bloom so you are already most of the way there.
- 3
Tune bloom, then export
Nudge Bloom until the bright areas glow the way you remember, add a touch of Aberration for that old-sensor fringe, and download in full quality.
A CCD recipe that works
If you want to dial it in by hand, this is a reliable starting point. Adjust to taste. Bloom and a cool cast do most of the work.
CCD vs the other retro looks
The CCD look leans cool and glowing, where the disposable-camera look leans hot and flashed, and the 2000s look leans warm and faded. If your photo feels too cool, try the warmer 2000s preset instead.
Why digital cameras are trending again
What is driving people back to fifteen-year-old compacts, and what they are actually buying.
Try another look
Not after a whole look? You can also stamp a date on it or go black and white. The rest are on the tool list.
